ET16KX(X)

Max. Capacity 4,000 lb
Crane Rating 16,000 ft-lb
Max. Reach 16 ft | 20 ft
Min. Truck Size Needed (GVWR) Class 3 (10,500 lb)
Get A Quote

The best crane for a reinforced service body.

The Venturo ET16KX is the ideal crane for a reinforced service body, allowing operators a crane application without the need for a crane service body.  With a maximum capacity of 4,000 lbs, the ET16KX can provide the strength for a majority of jobsites on a standard service truck.  The ET16KXX-20 is also available with full-hydraulic boom extension to 20 ft.  Both cranes offer optional proportional controls which allows the operator to manage the speed of the crane.

Get A Quote Contact Sales

PRODUCT FEATURES

Two Variations of Crane
The ET16KX comes in two configurations giving operators greater productivity at their jobsite.  The ET16KX comes with 4′ Hydraulic Extension/4′ Manual Extension to 16′, the ET16KXX-20 comes with full-hydraulic extension 10′ – 20′.

DC Winch
The ET series winches combine a powerful permanent magnet DC motor with robust sealing with proven 3-stage all metal geartrain. Permanent grease lubrication means years of trouble free service.

Manual Crane Override
Each ET series crane gives the user the ability to operate and stow the crane if there is power loss through the remote controls.  These functions allow boom-retract, boom-down and winch functions.

Proportional Control
The ET16KX and ET16KXX-20 both have optional proportional controls which allow the crane operator to manage the speed of the hydraulic functions on the crane.  This gives them more control over load speeds.

Get A Quote

specifications

  • Maximum Lift Capacity
  • 4,000 lb (1,814 kg)
  • Crane Rating
  • 16,000 ft-lb
  • Maximum Reach
  • ET16KX: 16 FT | ET16KXX-20: 20 FT
  • Boom Extension
  • ET16KX: Hydraulic: 8 ft - 12 ft, Manual: 12 ft - 16 ft
  • ET16KXX-20: Hydraulic: 10 ft - 16 ft - 20 ft
  • Rotation
  • 360° Continuous Power
  • Power Source
  • Electric-Hydraulic (12V DC)
  • Wire Rope
  • 80 ft of 5/16" Aircraft-Quality Wire Rope
  • Stowed Height
  • 26-5/8"
  • Mounting Space
  • 14" x 14" Mounting Plate
  • Weight
  • 1,020 lb
  • Minimum GVWR
  • 10,500 lb

standard features

  • ✔ Capacity Overload Shut-Off System
  • ✔ Anti-Two Blocking System
  • ✔ 25 ft Remote Control Pendant with Quick Disconnect
  • ✔ Load block with swivel hook safety latch
  • ✔ Master Disconnect Switch Kit
  • ✔ 25 ft, 2-gauge battery cable

minimum requirements

  • Class 3 (10,500 lb GVWR Chassis)
  • Rear Outriggers
  • Electric Power Source: 12V DC

optional equipment

  • Proportional Controls
  • Wireless FM Remote Control with Onboard Diagnostic System and Receiver
  • Capacity Overload Alarm
  • Electric/Hydraulic Outrigger Packages
  • Mounting Pedestal for platform bodies (36")
  • Adjustable Boom Rest (18" - 26")
  • 250 AMP Circuit Breaker Kit
  • Custom Paint (Solid color, single-stage Imron, non-metallic)
