ET6K

Max. Capacity 2,000 lb
Crane Rating 6,000 ft-lb
Max. Reach 10 ft
Min. Truck Size Needed (GVWR) Class 2 (8,000 lb)
Get A Quote

Low-Cost, Low-Weight, Operator Certification Exempt

The Venturo ET6K service crane is a 6,000 ft.-lbs. crane with 2,000 lb. lifting capacity featuring electric winch, power rotation and hydraulic boom elevation with a single, manual extension up to 10 ft.

Showroom Display available for this crane.

Get A Quote Contact Sales

PRODUCT FEATURES

Power Features with Low-Cost
For those looking for a lower-cost crane with more options, the ET6K features power rotation and elevation with a 10 ft maximum reach.

Crane Operator Qualification Exempt
You won’t have to qualify your crane operators with this crane since it falls under the capacity requirements but still gives your workers a powered crane.

Get A Quote

specifications

  • Maximum Lift Capacity
  • 2,000 lb (907 kg)
  • Crane Rating
  • 6,000 ft-lb
  • Maximum Reach
  • 10 ft
  • Boom Extension
  • Manual 6 ft - 10 ft
  • Rotation
  • 360° Continuous Power
  • Power Source
  • Electric-Hydraulic (12V DC)
  • Wire Rope
  • 50 ft of 3/16" Aircraft-Quality Wire Rope
  • Stowed Height
  • 24-1/4"
  • Mounting Space
  • 10-1/2" x 10-1/2" Mounting Plate
  • Weight
  • 380 lb
  • Minimum GVWR
  • 8,000 lb

standard features

  • ✔ Electric Winch/Rotation
  • ✔ Hydraulic Boom Elevation
  • ✔ Anti-Two Blocking Kit
  • ✔ Capacity Overload Shut-Off System
  • ✔ 20 ft Remote control pendant with Quick Disconnect
  • ✔ Load block with swivel hook safety latch
  • ✔ Master Disconnect Switch Kit
  • ✔ 25 ft, 4-gauge battery cable

minimum requirements

  • Class 2 (8,000 lb minimum GVWR chassis)
  • Outrigger Packages (Crankdown/Side-Bracket/Fold-Away)
  • Electric Power Source: 12V DC

optional equipment

  • Wireless FM Remote Control with Onboard Diagnostic System and Receiver
  • Capacity Overload Alarm
  • Mounting Pedestal for platform bodies (21" or 36")
  • Adjustable Boom Rest (13" - 19")
  • 250 AMP Circuit Breaker Kit
  • Custom Paint (Solid color, single-stage Imron, non-metallic)
