ET12KX-15

Max. Capacity 3,500 lb
Crane Rating 12,000 ft-lb
Max. Reach 15 ft
Min. Truck Size Needed (GVWR) Class 2 (8,800 lb)
Get A Quote

Setting the standard for electric-hydraulic service cranes.

The Venturo ET12KX-15 service crane is a versatile application that is neither too large or too small for a majority of lifting jobs. This crane has been utilized heavily in municipal/public works industry lifting anything from service equipment to fire hydrants throughout the United States. With a 12,000 FT-LB rating and a 3,500 LB maximum capacity, the ET12KX-15 can be installed on trucks with a minimum 8,800 GVWR.

Showroom Display available for this model.

Get A Quote Contact Sales

PRODUCT FEATURES

Versatility
The ET12KX-15 is the perfect mid-size crane for a majority of applications and industry’s.  The 3,500 lb maximum capacity gives operators a service crane that can complete most jobs.

Hydraulic/Manual Boom Extension
The standard boom configuration for the ET12KX-15 is a 4′ Hydraulic boom extension with a 4′ Manual pullout boom extension.

Powerful DC Electric Winch
The ET series winches combine a powerful permanent  magnet DC motor with robust sealing with proven 3-stage, all metal geartrain.  Permanent grease lubrication means years of trouble-free service.



Get A Quote

specifications

  • Maximum Lift Capacity
  • 3,500 lb (1,588 kg)
  • Crane Rating
  • 12,000 ft-lb
  • Maximum Reach
  • 15 ft
  • Boom Extension
  • Hydraulic: 7 ft - 11 ft, Manual: 11 ft - 15 ft
  • Rotation
  • 360° Continuous Power
  • Power Source
  • Electric-Hydraulic (12V DC) - Electric Winch, Hydraulic Rotation, Elevation & Extension
  • Wire Rope
  • 65 ft of 1/4" Aircraft-Quality Wire Rope
  • Stowed Height
  • 26-1/4"
  • Mounting Space
  • 14" x 14" Mounting Plate
  • Weight
  • 700 lb
  • Minimum GVWR
  • 8,800 lb

standard features

  • ✔ Capacity Overload Shut-Off System
  • ✔ Anti-Two Blocking System
  • ✔ 25 ft Remote Control Pendant with Quick Disconnect
  • ✔ Load block with swivel hook safety latch
  • ✔ Master Disconnect Switch Kit
  • ✔ 25 ft, 2-gauge battery cable

minimum requirements

  • Class 2 (8,800 lb GVWR Chassis)
  • Outrigger Packages (Crankdown/Side-Bracket/Fold-Away)
  • Electric Power Source: 12V DC

optional equipment

  • Proportional Controls - Rotation, Elevation & Extension
  • Wireless FM Remote Control with Onboard Diagnostic System and Receiver
  • Capacity Overload Alarm
  • Cable Overhaul Weight
  • Electric/Hydraulic/Manual Outrigger Packages
  • Mounting Pedestal for platform bodies (21" or 36")
  • Adjustable Boom Rest (13" - 19")
  • 250 AMP Circuit Breaker Kit
  • Custom Paint (Solid color, single-stage Imron, non-metallic)
